AEMC 2135.60 Ground Resistance Tester - w/o Probes (Cat #2135.48 & Cat. #2135.36)

SKU: N104199
Model: 2135.60
Product Condition: New
$3,314.55

AEMC 2135.60 Ground Resistance Tester provides ground resistance, soil resistivity, bond resistance, current, and voltage measurement capabilities with auto-ranging operation up to 99.99 kΩ.

Read more
Estimated delivery: 5 days
One year warranty
Free return within 30 days of purchase.
Contact
Have a question ? Ask an expert
Live chat (833) 322-7865 Email
Browse by category:
AEMC Ground Resistance Testers Electrical Testing Equipment
Product Description

Ground Resistance Measurement for Electrical Grounding Systems

The AEMC 2135.60 Ground Resistance Tester is a portable earth resistance testing instrument designed for grounding system analysis and verification. It performs ground resistance, bond resistance, soil resistivity, current, and voltage measurements using multiple test methods. The platform supports installation, commissioning, and maintenance of electrical grounding systems.

Multi-Method Resistance Measurement Operation

• Performs 3-pole and 4-pole earth resistance measurements using auxiliary electrode testing methods
• Measures bond and connection resistance using 2-pole and 4-pole Kelvin sensing techniques
• Calculates soil resistivity using selectable Wenner and Schlumberger methods
• Automatically selects measurement range, frequency, and test current during operation
• Supports selective and clamp-assisted grounding measurements with compatible accessories

Ground Testing Functions and Measurement Capabilities

• Ground resistance measurement range from 0.01 Ω to 99.99 kΩ
• Bond resistance measurement with test currents up to 250 mA
• Soil resistivity measurement with automatic resistivity calculation up to 999 kΩm
• Current measurement capability from 0.01 mA to 40 A
• External voltage measurement from 0.1 V to 65 V AC/DC with onboard memory storage

Grounding System Testing Applications

• Ground electrode resistance testing
• Soil resistivity evaluation for grounding system design
• Bonding and grounding system maintenance testing

Specifications
Specifications
MPN 2135.60
Product Condition New
Shipping Length (in.) 16
Shipping Width (In.) 14
Shipping Height (In.) 10
Item Returns This item can be returned
SpecificationValue
BrandAEMC
Model6424
MPN2135.60
Ground Resistance (4-Point)0.01 Ω to 99.99 kΩ
Ground Resistance (3-Point)0.09 Ω to 99.9 kΩ
Ground Resistance Accuracy±(2% Reading +1 ct)
Ground Resistance Test CurrentUp to 250 mA
Ground Resistance Test Voltage16 V or 32 V
Soil Resistivity MethodWenner or Schlumberger
Soil Resistivity Range0.01 Ω to 99.9 kΩ; ρ max 999 kΩm
2-Clamp Ground Measurement0.1 Ω to 500 Ω
DC Resistance 2-Pole Range0.12 Ω to 99.9 kΩ
DC Resistance 4-Pole Range0.020 Ω to 99.99 kΩ
Current Measurement Range0.01 mA to 40 A
External Voltage Measurement0.1 V to 65 V AC/DC
Memory Capacity512 Measurements (64 KB)
Communication InterfaceUSB 2.0 Optically Isolated
Power Source9.6 V Rechargeable Battery Pack
Battery Life1500 Tests Typical
Dimensions10.7 x 9.8 x 5.12 in (272 x 248 x 130 mm)
Weight7 lb (3.2 kg)
Case MaterialUL V0 Polypropylene
Ingress ProtectionIP53 (Cover Closed)
Operating Temperature32°F to 113°F (0°C to 45°C)
Storage Temperature-40°F to 158°F (-40°C to 70°C)
Relative HumidityUp to 90% RH
Safety RatingIEC 61010-1, EN 61557, 50 V CAT IV
EMC ComplianceEN 61326-1
What's in the box?
  • 1 x AEMC 2135.60 Ground Resistance Tester
