Fluke 750P08 Gauge Pressure Module 0-1000 psi 70 bar

The Fluke 750P08 Gauge Pressure Module transforms your multifunction calibrator into a precise, high-performance pressure calibrator — ideal for field technicians, instrumentation engineers, and calibration labs. With a full-scale gauge range of 0–1000 psi (0–70 bar / 0–7000 kPa) and robust digital sensing, it delivers accurate and traceable pressure measurements with minimal setup time and maximum flexibility.

Key Features

• Wide Pressure Range & High Accuracy

  • Measures gauge pressure from 0 to 1000 psi (0–70 bar / 0–7000 kPa). Offers reference uncertainty up to 0.01% (depending on module) for precision calibration.

• Digital Communication to Calibrators

  • Communicates digitally with compatible calibrators (e.g. 725, 726, 750 series), avoiding analog drift or signal losses.

  • Enables display in up to 11 different engineering units at the touch of a button.

• Simple, Versatile Operation

  • Connects to a pressure source (pump or process) and the calibrator using quick-connect fittings; no tools required.

  • Compatible adapters included (NPT, BSP, M20) to suit different pressure systems.

• Independent, Traceable Calibration Module

  • Can be swapped between calibrators without loss of accuracy or traceability.

  • Suitable for documenting calibrations, with date/time stamping when used with a documenting calibrator.

Benefits

• Cost-Effective Calibration Solution — Instead of buying a dedicated pressure calibrator, use this module with existing multifunction calibrators for full pressure calibration capability.

• High Precision & Traceability — Ensures accurate, repeatable pressure readings suitable for industrial calibration workflows and regulatory compliance.

• Flexibility & Compatibility — Works with multiple calibrator series and supports a broad range of pressure systems due to included adapters.

• Fast, Reliable Operation — Digital communication and easy connect/disconnect minimize errors, reduce downtime, and streamline calibration tasks.
